DFM for CNC Machining: Features That Cut Cost

DFM for CNC machining starts with a simple question: can this geometry be cut in fewer setups with standard tools? A short manufacturability review before quoting often removes cost that no shop can negotiate away later. Focus on tool access, setup count, tolerances, and finish.

Start with tool access. Avoid deep, narrow pockets and internal corners smaller than the cutter radius. For a typical 6 mm end mill, specify corner radii of at least 3 mm, or use a smaller tool only where it earns its cost. Keep floors and walls reachable from one direction. Standard hole sizes, common thread pitches, and generous radii reduce programming, cycle time, and scrap on 6061-T6, 7075, 303 stainless, and POM/Delrin alike.

Consolidate setups. A part that needs three orientations may cost far more than one that can be machined from two, especially in small batches. Add datum features that let the shop locate the part repeatably, and avoid tight tolerances on non-functional surfaces. ISO 2768-m is often enough for clearance features, while bearing bores or press fits may need ±0.02 mm or finer.

Specify finishes deliberately. Ra 3.2 µm is usually fine for most machined surfaces; reserve Ra 0.8 µm for sealing, sliding, or cosmetic areas. If a design for manufacturability review flags a feature that adds a fourth setup or a custom tool, changing it early is cheaper than discovering it after heat treat. Send the model with tolerances, material, and finish callouts so the quote reflects the real part.
